Soft-Close Metal Drawer-Box Trash Pullout

A clean-lined solution for a beautifully organized kitchen. This low-sided metal drawer-box pullout hides waste behind your cabinet door and glides open on synchronized soft-close slides. Grey bins and coordinated grey surfaces create a streamlined, modern interior.

Smart details

• Thin double-wall metal drawer sides maximize usable space and make bins easy to lift out.
• 500-series full-extension, synchronized soft-close concealed undermount slides.
• 100 lb load capacity for the organizer, separate from shipping weight.
• Ships preassembled with one or two heavy-duty grey polymer bins, according to your selected configuration.
• Mounts to the cabinet floor with four screws. Integrated brackets inside the drawer box attach to your cabinet door.
• Designed for face-frame or frameless cabinetry with the required clear opening.

Sizes, models and pricing

Single 35 qt — 12-inch opening
CAN-MDB5-S35G
Overall dimensions from the technical drawing: 12 W × 21-5/16 D × 19-15/16 H inches.
Typical cabinet: 15-inch base. Minimum clear opening: 12 inches.
Manufacturer list: $385.60   MDI price: $329.69

Double 35 qt — 15-inch opening
CAN-MDB5-D35G
Overall dimensions from the technical drawing: 15 W × 21-3/16 D × 19-15/16 H inches.
Typical cabinet: 18-inch base. Minimum clear opening: 15 inches.
Manufacturer list: $436.47   MDI price: $373.18

Double 50 qt — 15-inch opening
CAN-MDB5-D50G
Overall dimensions from the technical drawing: 15 W × 21-3/16 D × 24-3/16 H inches.
Typical cabinet: 18-inch base. Minimum clear opening: 15 inches.
Manufacturer list: $469.82   MDI price: $401.69

Measure for a smooth installation

Use the technical-drawing dimensions above when planning fit; the online summary rounds depth to 21 inches. Check interior clearance around hinges, framing and anything above the bins. Cabinet and decorative door are not included. The gallery shows a representative double 50-quart installation; the single version has one bin and both 35-quart versions are shorter.
