500 Series 105° Pie-Corner Self-Closing Cabinet Hinge

$7.20

A dedicated pie-corner hinge for folding corner-cabinet doors. The angled arm and cam adjustment support the door-to-door connection in a compatible corner arrangement.

Exact model: 500.0U22.75; 105° opening and 18 mm crank.
Standard-duty self-closing action.
Press-in installation with 8 mm dowels.
35 mm cup bore, 11.2 mm cup-bore depth, 45 mm mounting centers and 65 mm hinge length.
Overlay adjustment ±2 mm; depth adjustment +3 / −2 mm.
Polished nickel steel; compatible with 400 Series mounting plates.
Limited lifetime manufacturer warranty.

Sold individually. Mounting plates and adjacent-door hinges are sold separately. Verify the folding-door layout, door thickness and boring before ordering.
