500 Series 45° Corner-Cabinet Self-Closing Hinge

$6.95

Designed for a 45° corner-cabinet application, this standard-duty concealed hinge provides spring-assisted closing and cam adjustment for clean door alignment.

Exact model: 500.0N20.75; inside-corner overlay with an 18 mm crank.
Press-in installation with 8 mm dowels.
35 mm cup bore, 11.2 mm cup-bore depth and 45 mm mounting centers.
64 mm hinge length; polished nickel steel.
Overlay adjustment ±2 mm; depth adjustment +3 / −2 mm.
Compatible with 400 Series mounting plates.
Limited lifetime manufacturer warranty.

Sold individually. Mounting plate and other optional hardware sold separately. Confirm the corner geometry, door boring and matching plate before ordering.
