Controlled closing. Precise adjustment. Protected clearances.
Soft-Close Cabinet Hinges
MDI uses Blum 110° soft-close hinges to give full-overlay cabinet doors smooth closing, dependable adjustment, and tool-free CLIP removal—with angle restrictors where walls, appliances, or neighboring fronts require tighter control.
The hinge affects every cabinet-door interaction
Why MDI Uses Blum 110° Soft-Close Hinges
A concealed hinge is small, but its performance is repeated every time a cabinet door opens and closes. MDI specifies Blum 110° soft-close hardware because it combines a useful opening angle, integrated BLUMOTION damping, precise door adjustment, and CLIP mounting in one proven hinge system.
The goal is not merely to prevent slamming. Correct hinges help doors close consistently, maintain controlled reveals, detach for service or installation, and operate without damaging nearby walls, appliances, pulls, or adjacent doors.
MDI Hinge Standard
- Blum CLIP top BLUMOTION 110° hinge
- Full-overlay application matched to cabinet construction
- Integrated soft-close mechanism
- Three-dimensional front adjustment
- Tool-free door attachment and removal at the mounting plate
- Angle restriction added where required by the layout
The hardware behind the door
Blum 71B3580: 110° CLIP top BLUMOTION
The Blum 71B3580 is a nickel-plated, full-overlay CLIP top BLUMOTION hinge with a press-in/knock-in cup. Its integrated damping system controls the final portion of the closing motion while the concealed cup-and-arm geometry keeps the hardware inside the cabinet.
Soft close is a system—not a sticker
What the Hinge Must Do Well
Control the Close
Integrated BLUMOTION slows the door near the cabinet so it closes quietly and with less impact than an uncontrolled self-closing hinge.
Hold Alignment
Height, side, and depth adjustment allow the installer to refine door position and maintain consistent reveals across a full-overlay elevation.
Release for Service
The CLIP connection lets the door detach from the mounting plate without removing the plate from the cabinet side.
Match the Door
Door height, width, weight, material, and use determine hinge quantity and whether damping should be active on every hinge.
A small clip can prevent an expensive collision
Blum 70T3553 Hinge Restrictors for Tight Areas
The black Blum 70T3553 opening-angle stop is designed for compatible CLIP top BLUMOTION 110° hinges. Once installed in the hinge mechanism, it reduces the opening angle from 110° to approximately 86°.
That controlled stop is useful when a full swing could put the cabinet door or pull into a perpendicular wall, appliance panel, refrigerator handle, neighboring cabinet front, or another obstruction. The restrictor remains discreet inside the hinge system and is virtually hidden when the door is closed.
Blum instructs installers to place an opening-angle stop on every hinge used on the affected door so the hinges share the same controlled opening condition.
Where MDI May Specify an 86° Stop
- Cabinet door immediately beside a wall
- Door near a refrigerator or appliance handle
- Perpendicular cabinet runs at a tight inside corner
- Tall doors beside projecting trim or panels
- Adjacent fronts or pulls with intersecting swing paths
- Any opening where 110° creates a collision risk
Geometry matters before the cabinets arrive
Hinge Planning in the Cabinet Layout
A restrictor can solve many tight-clearance conditions, but it should not be used to excuse a poor layout. Door thickness, overlay, pull projection, filler width, appliance clearance, wall position, and neighboring opening paths should be reviewed together.
Walls & Fillers
A filler can move the door and pull away from a wall, allow trim clearance, and improve access. The required width depends on the actual door, hinge, pull, and field condition.
Appliance Interfaces
Refrigerator doors, handles, oven doors, and service clearances can conflict with cabinet fronts unless their full operating positions are shown before ordering.
Inside Corners
Perpendicular doors and drawers require enough separation for pulls, fronts, and hands. Restrictors may protect the intersection after spacing is resolved.
Adjustment protects the finished elevation
Installation, Adjustment & Maintenance
Soft-close performance depends on more than the damper. Cabinets must be installed level and square, mounting plates must be secure, hinge cups must be drilled accurately, and doors must be adjusted without forcing the mechanism beyond its intended range.
Large or heavy fronts may require additional hinges. Small or lightweight doors may need damping deactivated on selected hinges so the door can close reliably. Final operation should be checked with shelves loaded, appliances installed, pulls attached, and every neighboring door or drawer opened through its full path.
Final Hinge Check
- Door closes fully without excessive force
- Reveals remain consistent across the elevation
- Cups and mounting plates remain secure
- No contact with walls, pulls, appliances, or adjacent fronts
- Restrictors installed on every hinge of the affected door
- Door removes and reattaches cleanly at the CLIP connection
Continue through the cabinet system
Related Cabinet Quality Details
Soft-Close Drawer Slides
Compare full-extension access, closing control, adjustment, and the hardware supporting loaded drawers.
Long-Term Cabinet Value
See how hinges, drawers, finishes, layout, and installation work together to support durability and buyer appeal.
Cabinet Collections
Compare MDI door styles and cabinet paths after the functional hardware requirements are understood.
Soft-close hinge questions
Soft-Close Hinge FAQs
What soft-close hinges does MDI use?
MDI uses Blum 110° soft-close hinges, including CLIP top BLUMOTION full-overlay applications selected to match the cabinet construction, overlay, mounting plate, door, and drilling pattern.
What does integrated BLUMOTION do?
Integrated BLUMOTION dampens the final closing movement so the cabinet door closes in a controlled manner. On compatible hinges, the damping function can be deactivated when a small or lightweight front requires less resistance.
What does the Blum 70T3553 restrictor do?
The 70T3553 opening-angle stop fits compatible Blum CLIP top BLUMOTION 110° hinges and limits their opening angle to approximately 86°, helping prevent contact with nearby walls, appliances, pulls, or cabinet fronts.
Does every hinge on the door need a restrictor?
Yes. Blum instructs installers to fit an opening-angle stop on all hinges used on the affected door so every hinge follows the same restricted opening path.
Can a hinge restrictor replace a cabinet filler?
Not automatically. A restrictor controls the opening angle, while a filler creates physical separation from walls, trim, appliances, or perpendicular fronts. Some conditions need one, the other, or both after the complete geometry is reviewed.
